| Specification | Details |
|---|---|
| Brand | Copeland |
| Model | CR36K6-PFZ |
| Compressor Type | Hermetic Reciprocating Compressor |
| Refrigerant | R22 |
| Nominal Capacity | 3 HP |
| Voltage | 220–240V |
| Phase | Single Phase |
| Frequency | 50 Hz |
| Cooling Capacity | Up to 30,100 Btu/hr* |
| Application | Air Conditioning & Heat Pump |
The Copeland CR36K6-PFZ Reciprocating Compressor is a hermetic reciprocating compressor designed for high-temperature air-conditioning and heat-pump applications. Copeland documentation identifies the CR36K6-PFZ family as an R22 compressor, with the PFZ configuration using 220–240V single-phase power.
Original price was: ₹15,000.00.₹11,000.00Current price is: ₹11,000.00.
The Copeland CR36K6-PFZ is a robust hermetic reciprocating compressor from the Copeland CR series. It is designed for reliable performance in air-conditioning and heat-pump applications, particularly where dependable R22 compression is required.
The compressor uses proven reciprocating connecting-rod technology and is designed for high-temperature/HBP applications. The CR36K6-PFZ configuration is specified for R22 refrigerant and 220–240V, 50Hz, single-phase operation.
Under the published rating conditions, the CR36K6-PFZ provides approximately 30,100 Btu/hr ASRE/T cooling capacity and 29,300 Btu/hr under ARI conditions, with a nominal rating of 3 HP. Its displacement is approximately 59.65 cm³/rev, with a 1.33 L oil charge and approximately 34.9 kg net weight.
The compressor is suitable for compatible commercial air conditioners, heat pumps, AC condensing units and other HVAC applications. The exact performance depends on evaporating temperature, condensing temperature and system operating conditions.
The CR36K6-PFZ is primarily specified for air-conditioning and heat-pump duty.
| Specification | Details |
|---|---|
| Brand | Copeland |
| Model | CR36K6-PFZ |
| Compressor Type | Reciprocating, Connecting Rod Type |
| Refrigerant | R22 |
| Application Group | High Temperature (HBP) |
| Nominal Capacity | 3 HP |
| Rated Voltage | 220–240V |
| Phase | Single Phase |
| Frequency | 50 Hz |
| Cooling Capacity | 30,100 Btu/hr ASRE/T |
| ARI Cooling Capacity | 29,300 Btu/hr |
| Input Power | 2,720 W |
| Input Current | 13.6 A |
| Displacement | 59.65 cm³/rev |
| Number of Cylinders | 2 |
| Oil Charge | 1.33 L |
| Net Weight | Approx. 34.9 kg |
| Compressor Cooling | Fan Cooled |
Cooling capacity is dependent on the published rating conditions and actual system operating conditions.
Copeland’s CR series is designed with rugged reciprocating technology, strong liquid-handling capability and suitability for high-ambient conditions.
