| Specification | Details |
|---|---|
| Brand | Danfoss |
| Model | SH120A4LC |
| Compressor Type | Hermetic Scroll Compressor |
| Refrigerant | R410A |
| Voltage | 380–415V / 460V |
| Phase | Three Phase |
| Frequency | 50/60 Hz |
| Application | Commercial Air Conditioning & HVAC |
The Danfoss SH120A4LC Scroll Compressor is a high-performance hermetic scroll compressor designed for R410A commercial air conditioning systems. It offers excellent energy efficiency, reliable performance and long service life for demanding HVAC applications.
₹6,000.00
The Danfoss SH120A4LC Scroll Compressor is part of the trusted SH Series of commercial scroll compressors. Designed specifically for R410A refrigerant, it delivers outstanding cooling capacity, quiet operation and exceptional reliability in commercial air-conditioning systems.
The compressor operates on 380–415V, Three Phase, 50Hz or 460V, Three Phase, 60Hz power supply. It features 116.90 cm³ swept volume, 3.30 L POE oil charge, fixed-speed scroll technology, internal overload motor protection, IP54 protection class, and robust construction for continuous-duty HVAC applications.
The SH120A4LC is widely used in rooftop packaged units, ducted air conditioning systems, chillers, VRF/VRV equipment, commercial buildings, hotels, hospitals, shopping malls and industrial HVAC systems. Its scroll technology ensures low vibration, quiet performance and excellent energy efficiency.
CR Technology supplies genuine Danfoss SH120A4LC scroll compressors with competitive pricing, technical support and fast delivery across India.
| Specification | Details |
|---|---|
| Brand | Danfoss |
| Model | SH120A4LC |
| Series | SH |
| Compressor Type | Hermetic Scroll |
| Refrigerant | R410A |
| Voltage | 380–415V / 460V |
| Phase | Three Phase |
| Frequency | 50/60 Hz |
| Swept Volume | 116.90 cm³ |
| Oil Type | POE 160SZ |
| Oil Charge | 3.30 L |
| Maximum Operating Current | 24 A |
| Rated Load Current | 20.7 A |
| Locked Rotor Current (LRA) | 142 A |
| Protection Class | IP54 |
| Motor Protection | Internal Overload Protector |
| Application | Commercial Air Conditioning |
