| Specification | Details |
|---|---|
| Brand | Danfoss |
| Model | SC10DL-104L2525 |
| Compressor Type | Hermetic Reciprocating Compressor |
| Refrigerant | R404A / R507 / R407C |
| Application | MBP / HBP |
| Voltage | 220–240V |
| Phase | Single Phase |
| Frequency | 50 Hz |
| Displacement | 10.29 cm³ |
| Motor Type | CSIR |
| Oil Charge | Approx. 600 cm³ |
The Danfoss SC10DL-104L2525 Reciprocating Compressor is a compact hermetic compressor designed for medium- and high-temperature refrigeration applications. Danfoss specifies the 104L2525 for R404A/R507 and R407C, with 220–240V, 50Hz operation.
The Danfoss SC10DL-104L2525 is a compact hermetic reciprocating refrigeration compressor from Danfoss’s SC series. It is designed for reliable operation in medium-temperature (MBP) and high-temperature (HBP) commercial refrigeration applications.
The compressor has a 10.29 cm³ displacement and operates on a 220–240V, 50Hz single-phase power supply. Danfoss lists the 104L2525 for R404A, R507 and R407C refrigerants, with an application evaporating-temperature range of approximately -20°C to +15°C.
The SC10DL is suitable for refrigeration equipment where a compact, reliable compressor is required. Danfoss’s SC-series range is intended for light-commercial refrigeration applications, while the wider Danfoss reciprocating portfolio covers applications such as commercial refrigeration, cold rooms, milk tanks and other cooling equipment.
The compressor’s CSIR motor design and high-starting-torque configuration make it suitable for refrigeration systems requiring dependable starting performance. The published technical data also specifies a maximum refrigerant charge of approximately 1.3 kg and a compressor weight of around 13 kg.
Danfoss identifies its light-commercial reciprocating compressors for applications including hotels, restaurants, catering, food and beverage equipment, medical/laboratory equipment and mobile/telecom cooling.
| Specification | Details |
|---|---|
| Brand | Danfoss |
| Model | SC10DL-104L2525 |
| Compressor Type | Hermetic Reciprocating |
| Refrigerant | R404A / R507 / R407C |
| Application | MBP / HBP |
| Voltage | 220–240V |
| Frequency | 50 Hz |
| Phase | Single Phase |
| Voltage Range | 198–254V |
| Displacement | 10.29 cm³ |
| Motor Type | CSIR |
| Starting Type | High Starting Torque |
| Motor Size | Approx. 385 W |
| Oil Quantity | Approx. 600 cm³ |
| Maximum Refrigerant Charge | Approx. 1,300 g |
| Maximum Ambient Temperature | Approx. 38°C |
| Weight | Approx. 13.1 kg |
Specifications are based on Danfoss technical documentation for the 104L2525 variant.
The SC10DL-104L2525 provides different cooling capacities depending on evaporating and condensing conditions.
| Application | Example Cooling Capacity |
|---|---|
| MBP | Approx. 1,100 W at -10°C / 45°C |
| HBP | Approx. 1,919 W at +5°C / 50°C |
| ASHRAE HBP | Approx. 2,299 W at +5°C / 50°C |
Actual capacity varies according to refrigerant, evaporating temperature, condensing temperature and operating conditions.
