Danfoss Compressor SZ300A4PBE

General Information:

• Brand: Danfoss
• Model: SZ300A4PBE
• Made In: France
• Application: Commercial and industrial refrigeration, air conditioning

Technical Specifications:

• Refrigerants: R407C, R134a
• Voltage: 380-400V / 3-phase / 50Hz, 460V / 3-phase / 60Hz
• Locked Rotor Amps (LRA): 270 A
• Maximum Operating Pressure: 58 bar
• Pressure Limits: Low Side – 20 bar, High Side – 29.6 bar
• Temperature Limits: TS Min – 5°C, TS Max – 53°C
• Displacement: 332.1 cm³/rev
• Oil Type: POE (Polyolester)

High-performance scroll compressors like the Danfoss SZ300A4PBE are made for commercial and industrial air conditioning and refrigeration systems. It is appropriate for a variety of cooling applications due to its efficient operation with R407C and R134a refrigerants. It is designed to operate on 380–400V (50Hz) and 460V (60Hz) three-phase power, guaranteeing dependability and steady performance even under the most taxing circumstances. Large-scale refrigeration machines benefit greatly from the compressor’s strong beginning torque and locked rotor amperage (LRA) of 270A.

Pressure restrictions are 20 bar on the low side and 29.6 bar on the high side. The compressor is built to last and can tolerate a maximum operating pressure of 58 bar. Effective cooling is ensured by its displacement of 332.1 cm³ each revolution.
