| Specification | Details |
|---|---|
| Brand | Copeland |
| Model | CR22K6M-PF1 |
| Compressor Type | Reciprocating, Connecting Rod Type |
| Refrigerant | R22 |
| Application Group | High Temperature (HBP) |
| Voltage | 220–240V |
| Phase | Single Phase |
| Frequency | 50 Hz |
| Cooling Capacity | 19,000 Btu/hr (ASRE/T) |
| Nominal Capacity | 1.83 HP (ARI) |
| Application | Air Conditioning & Heat Pump |
The Copeland CR22K6M-PF1 Reciprocating Compressor is a hermetic connecting-rod compressor designed for R22 air-conditioning and heat-pump applications. Copeland specifies 220–240V, 50Hz, single-phase operation for this model.
Original price was: ₹6,000.00.₹5,500.00Current price is: ₹5,500.00.
The Copeland CR22K6M-PF1 is a reliable hermetic reciprocating compressor from the Copeland CR series. It is engineered for high-temperature (HBP) air-conditioning and heat-pump applications, providing dependable compression and stable cooling performance.
The compressor is designed for R22 refrigerant and operates on a 220–240V, 50Hz, single-phase power supply. Copeland specifies an evaporating-temperature range of approximately -23.3°C to 12.8°C, making the model suitable for a range of high-temperature HVAC operating conditions.
Under the published ASRE/T rating conditions, the CR22K6M-PF1 provides approximately 19,000 Btu/hr (5,563 W) cooling capacity. Under ARI conditions, the published cooling capacity is approximately 18,500 Btu/hr (5,417 W), with a nominal capacity of 1.83 HP.
The compressor has approximately 40.8 cm³/rev displacement, with 1,750 W input power and 8.4 A input current under the published rating conditions. Copeland also lists fan cooling at approximately 400 ft³/min.
The CR22K6M-PF1 is suitable for compatible air-conditioning systems, heat pumps and commercial HVAC equipment where an R22 reciprocating compressor is required.
Copeland’s official specification identifies the typical applications as air conditioning and heat pump systems.
| Specification | Details |
|---|---|
| Brand | Copeland |
| Model | CR22K6M-PF1 |
| Compressor Type | Reciprocating, Connecting Rod |
| Refrigerant | R22 |
| Application Group | High Temperature (HBP) |
| Voltage | 220–240V |
| Phase | Single Phase |
| Frequency | 50 Hz |
| ASRE/T Cooling Capacity | 19,000 Btu/hr |
| ARI Cooling Capacity | 18,500 Btu/hr |
| ASRE/T Capacity | 5,563 W |
| ARI Capacity | 5,417 W |
| Nominal Capacity | 1.83 HP |
| Input Power | 1,750 W |
| Input Current | 8.4 A |
| EER | 10.86 Btu/W-hr ASRE/T |
| Displacement | 40.8 cm³/rev |
| Compressor Cooling | Fan, approx. 400 ft³/min |
| Application | Air Conditioning & Heat Pump |
Specifications are based on Copeland’s official CR22K6M-PF1 product specification. Actual system capacity varies with operating conditions.
