Cooling Capacity: 71,500 W (Approx. 244,000 BTU/h / 20 Tons)
Power Supply: 380–420V / 3 Phase / 50Hz
Refrigerant: R410A
Energy Efficient: EER approx. 11.1
Max Current: 37.2 A (LRA: 272 A)
Oil Type: POE (RL32-3MAF)
Net Weight: 160 kg
Connections: 1 5/8″ Suction | 1 3/8″ Discharge
Protection: Internal motor protection, IP54 rated
Original price was: ₹128,000.00.₹115,000.00Current price is: ₹115,000.00.
The Copeland ZP295KCE-TWD-524 is a high-performance 25 HP hermetic scroll compressor engineered for R410A refrigerant in commercial air conditioning and heat pump systems. Designed to operate on 380–420V / 3 Phase / 50Hz, this model delivers powerful cooling capacity with high energy efficiency, quiet operation, and enhanced reliability.
Built for demanding HVAC environments, the ZP295KCE-TWD-524 is widely used in large roof-top units, chillers, and central air conditioning plants where consistent cooling and long service life are critical.
Model: ZP295KCE-TWD-524
Horsepower: 25 HP
Refrigerant: R410A
Voltage / Phase: 380–420V / 3 Phase / 50 Hz
Cooling Capacity: 71,500 W
Approx. 244,000 BTU/h
Approx. 20 Tons
Power Input: 21,667 W
Max Continuous Current: 37.2 A
MCC (Max Current): Up to 48.5 A
Locked Rotor Amperage (LRA): 272 A
Displacement: 46.7 m³/h (approx.)
Oil Type: POE (Polyolester) RL32-3MAF
Net Weight: 160 kg
Dimensions: 390 mm (L) × 447 mm (W) × 715 mm (H)
Connections:
Suction: 1 5/8 inch
Discharge: 1 3/8 inch
With an EER of approximately 11.1, the compressor is optimized for modern high-efficiency HVAC systems using R410A refrigerant. It supports reduced energy consumption while delivering stable cooling output.
The hermetic scroll design features up to 70% fewer moving parts compared to reciprocating compressors, resulting in:
Lower mechanical wear
Reduced vibration
Minimal noise levels
Extended service life
The scroll design provides enhanced tolerance to liquid refrigerant, reducing the risk of damage due to liquid flood-back and improving overall system reliability.
Engineered for high ambient conditions and heavy-duty commercial use, the compressor performs reliably across a broad range of operating temperatures.
Internal Motor Protection for enhanced operational safety
IP54 Protection Rating for improved resistance against dust and moisture
Robust electrical design suitable for industrial three-phase power supply
These built-in protections ensure dependable long-term performance in commercial installations.
The Copeland ZP295KCE-TWD-524 is ideal for:
Commercial Air Conditioning Systems
Centralized HVAC Plants
Industrial & Commercial Chillers
Large Rooftop Units (RTUs)
Heat Pump Systems
Process Cooling Applications
Its 20-ton cooling capacity makes it suitable for malls, hospitals, hotels, factories, data centers, and large office buildings.
High cooling capacity (71.5 kW)
Optimized for R410A systems
Energy-efficient performance
Low noise and vibration
Heavy-duty industrial construction
Reliable scroll compression technology
Suitable for export and bulk HVAC projects
The Copeland ZP295KCE-TWD-524 25 HP Hermetic Scroll Compressor is a dependable solution for high-capacity commercial cooling systems, offering efficiency, durability, and consistent performance in demanding air conditioning and heat pump applications.
